Aluminium Sliding Doors
Aluminium sliding doors are a sleek, space-saving solution for the modern home. By gliding horizontally along tracks, hey eliminate the need for swing space, making them perfect for optimizing floor layouts.
Featuring slim profiles and expansive glass panels, these doors maximize natural light and create a seamless transition between indoors and out. They combine minimalist aesthetics with smooth, durable functionality for a truly contemporary feel.
About Aluminium Sliding Doors
Aluminium sliding doors are a versatile and practical solution, engineered for smooth, horizontal operation. They function by having one or more panels slide past a fixed panel or into a wall pocket, eliminating the need for swing space. Unlike casement windows which are limited by hinge size, the design of a sliding door allows for expansive, floor-to-ceiling glass panels. This maximized glazing area delivers superior natural light penetration and offers an unobstructed, panoramic connection to the outdoor environment.
While aluminium sliding doors naturally provide expansive views, their structural design often leads to challenges with airtightness and operational friction compared to other window types. PA’s sliding aluminium doors are specifically engineered to minimize these issues, utilizing advanced sealing and reinforced mechanics to reduce drafts and ensure a smooth, reliable glide. By combining enhanced performance with an extremely narrow concealed frame, these doors deliver a high degree of comfort and a clean, minimalist aesthetic for any modern property.
PA Home Aluminium Sliding Door's High Light
Modern Aesthetics: Features an extremely narrow concealed side frame design to maximize views and natural light.
Superior Thermal Performance: Equipped with standard 5mm + 22A + 5mm double tempered insulated glass for maximized heat and noise reduction.
Premium Hardware & Security: Standardized with BaoGao hardware (optional protective operating lock with key) or an optional German SIEGENIA heavy lifting system.
Heavy-Duty Engineering: Built with 6060-T5 virgin aluminium profiles, featuring a robust 3.0mm fan wall thickness and 2.2mm frame wall thickness.
Smooth High-Capacity Operation: Engineered to handle massive glass weights of 200–400kg, ensuring reliable long-term performance for large panels.
Versatile Customization: Flexible options including mosquito net sashes, three-track systems, and corner-without-post designs.
Certified Quality: Verified by international standards, including ISO certification and adherence to Australian Standards (AS2047/AS1288).
Our Main Product of Aluminium Sliding Doors
C-M125 Aluminium Sliding Door
| Specification / Detail | |
|---|---|
| Product Appearance | Extremely narrow concealed side frame |
| Optional Configuration | Optional: Mosquito net sash, three tracks, corner without post; |
| Hardware Configuration | Optional BaoGao protective operating lock with key |
| Profile Thickness | 6060-T5 Virgin Aluminum, Fan Wall Thickness 2.0mm, Frame Wall Thickness 2.1mm; Main Profile 3.0mm |
| Box Width | 125/188mm |
| Opening Fan Width | 600mm – 1500mm |
| Opening Fan Height | 1600mm – 3000mm |
| Glass Configuration | Standard 5mm + 20A + 5mm Double Tempered Glass |
| Opening Method | Sliding |
450pa
Water Tightness performance
4.8 m³/(h·㎡)
AirTightness performance
35dB
Sound Insulation performance
2.3 W/(m²·K)
Termal Insulating Porperty
5.0k pa
Wind Pressure Resistance performance
C-M123 Narrow Frame Sliding Door
| Specification / Detail | |
|---|---|
| Product Appearance | Extremely narrow concealed side frame |
| Optional Configuration | Standard BaoGao one-word lock / Optional heavy lifting system |
| Hardware Configuration | Standard BaoGao / Optional German SIEGENIA heavy lifting system / Load capacity 200–400kg |
| Profile Thickness | 6060-T5 Virgin Aluminum, Fan Wall Thickness 3.0mm, Frame Wall Thickness 2.2mm |
| Box Width | 128mm |
| Opening Fan Width | 600mm – 1500mm (Single fan area ≤ 4.8m^2) |
| Opening Fan Height | 1600mm – 3000mm |
| Glass Configuration | Standard 5mm + 22A + 5mm Double Tempered Glass |
450pa
Water Tightness performance
4.8 m³/(h·㎡)
AirTightness performance
35dB
Sound Insulation performance
2.3 W/(m²·K)
Termal Insulating Porperty
5.0k pa
Wind Pressure Resistance performance
Precautions for using aluminum sliding doors
For optimal performance and longevity, always operate your aluminium sliding doors with smooth, steady pressure, avoiding forceful impacts that could strain the frame or hardware. It is essential to keep the tracks clear of dust, pebbles, or debris to ensure a seamless gliding motion and prevent mechanical wear. For the glass, use only soft cloths and neutral cleaners to maintain clarity without scratching the surface. Additionally, regularly check that drainage paths are unobstructed to prevent water buildup, and always ensure the door is fully locked when not in use to maintain structural integrity and security.
FAQs About Aluminium Sliding Door
Do sliding doors require a lot of maintenance?
No. Aluminium sliding doors are low maintenance — regular cleaning of glass and tracks is typically sufficient. Unlike timber, they don’t rot or warp, and powder‑coated finishes resist fading.
How do I choose the right aluminium sliding door system?
Important factors include:
Material quality and thermal performance
Glass specification
Security hardware
Installation service and warranty
Always ask suppliers for technical specs and installation recommendations.
Can I choose custom sizes and panel configurations?
Yes. Aluminium sliding doors are highly customizable — you can choose different numbers of panels, track arrangements, and glass options to suit your space.
What are the five most critical performance indicators for windows, and how do I interpret their technical ratings to assess quality and suitability?
1. Thermal Insulation (U-value)
Unit: W/(m²·K)
What it means: Measures the heat transfer rate through the window.
Key point: Lower values = better energy efficiency. Aim for a U-value ≤ 2.0 for high performance and reduced heat loss.
2. Air Tightness (Air Permeability)
Unit: m³/(m²·h)
What it means: Indicates the volume of air that leaks through the window’s seals each hour.
Key point: Lower values = fewer drafts and superior sealing. Aim for ≤ 2.0 for top-tier performance.
3. Water Tightness (Water Resistance)
Unit: Pascals (Pa)
What it means: Shows the maximum wind pressure the window can withstand before water leaks.
Key point: Higher values = better rain protection. For exposed areas, look for a rating of ≥350 Pa.
4. Wind Load Resistance (Structural Strength)
Unit: Pascals (Pa)
What it means: Measures the maximum pressure the window structure can handle without failure.
Key point: Higher values = better strength, essential for high-rise buildings and storm-prone regions.
5. Sound Insulation (Acoustic Performance)
Unit: Decibels (dB)
What it means: Indicates how well the window reduces external noise.
Key point: Higher dB ratings = quieter interiors. A rating of ≥ 30 dB is excellent for noise reduction.
