Aluminium Sliding Windows
An aluminium casement window is a smart, high-performance choice for modern homes. Its sash attaches to the frame by one or more hinges at the side, swinging outward to provide maximum ventilation and unobstructed views.
This sleek, slim-profile design makes it ideal for contemporary living, combining a tight weatherproof seal, stylish aesthetics, and effortless functionality.
About Aluminium Sliding Windows
Aluminium sliding windows are designed for seamless, effortless operation. With a smooth sliding mechanism, these windows glide open and closed horizontally, offering excellent space-saving benefits. Unlike casement windows that open outward, sliding windows don’t require additional clearance, making them ideal for smaller spaces or areas with limited room for window operation.
The sleek, minimalistic design of aluminium sliding windows provides unobstructed views and abundant natural light. Their durable aluminium frame offers excellent resistance to the elements, ensuring longevity and reduced maintenance requirements. With a space-efficient design, they maximize the available area, making them perfect for both residential and commercial settings.
While aluminium sliding windows offer smooth and easy operation, they can sometimes be less airtight compared to casement windows, as they rely on a sliding track that can have small gaps. This can result in less thermal performance, especially in extreme weather conditions. However, with the use of modern weather seals and advanced materials, these challenges can be mitigated to provide satisfactory insulation.
PA Home Aluminium Sliding Window
1. Safety & High Performance: The window is designed with an integrated limit opening width to enhance security, particularly for high-rise buildings and family settings. The multi-layer insulated glass (5mm + 12A + 5mm) features a 12mm spacer for superior heat and noise reduction, while the ultra-wide thermal break within the aluminium profile ensures outstanding energy efficiency.
2. Premium Hardware: Equipped with HAOPU’s high-quality hardware, ensuring smooth, reliable, and long-lasting operation for enhanced user experience and durability.
3. In-house Manufacturing & Customization: Manufactured in our own factories, the windows offer customizable dimensions and a wide range of color options, catering to diverse design needs and ensuring high-quality control.
4. Certified Quality: All products are verified by international standards, including ISO certification, ensuring compliance with rigorous quality benchmarks.
🪟 Aluminium Casement Windows Core Product
| Component / Feature | Current Specification | Detailed Context / Notes |
|---|---|---|
| Frame Material | 6060-T5 Virgin Aluminium | Bottom frame thickness is 2.9mm / sash profile thickness is 1.8mm. |
| Thermal Break & Sealing System | Polyamide Thermal Break & Integrated Foldable Gasket | Ultra-wide thermal break for enhanced insulation and energy efficiency. One-piece foldable gasket design for superior sealing. |
| Operating Method | Sliding Window | Designed for smooth sliding operation. |
| Hardware Accessories | HAOPU Hidden Automatic Lock | Locking system with hidden automatic locking feature, available in black or silver finish. |
| Product Appearance | 30mm Visible Frame Width | The window features a 30mm visible frame width. The hardware is hidden from the front, providing a sleek and modern aesthetic. |
| Options | Included Screen | Standard mesh screen is included with the window, but it can be omitted if desired. |
| Additional Features | Multiple Security and Weather Resistance Features | The window features an automatic locking system and is resistant to high winds, heavy rain, and extreme temperatures. It also includes a tightly sealed structure for enhanced energy efficiency and environmental stability. |
| English Name | Specification / Detail |
|---|---|
| Profile Thickness | 6060-T5 Virgin Aluminium, Main Profile Thickness 2.9mm / Sash Profile Thickness 1.8mm |
| Box Width | 128mm |
| Opening Fan Width | 600mm – 1500mm (Single Fan Area Not Exceeding 3.5m²) |
| Opening Fan Height | 600mm – 2000mm |
| Glass Configuration | 5mm + 15A + 5mm |
400pa
Water Tightness performance
4.8 m³/(h·㎡)
AirTightness performance
35dB
Sound Insulation performance
2.5 W/(m²·K)
Termal Insulating Porperty
4.3k pa
Wind Pressure Resistance performance
C-C118 Sliding Windows With Screen
| Component / Feature | Current Specification | Detailed Context / Notes |
|---|---|---|
| Profile Thickness | 6060-T5 Virgin Aluminium | Main Profile Thickness 1.4mm / Sash Profile Thickness 1.4mm |
| Hardware Accessories | HAOPU Hidden Automatic Lock | Automatic locking system with hidden hardware, offering a sleek look. |
| Opening Method | Two-Wheel / Three-Wheel | Available with two-wheel or three-wheel operation for smooth sliding. |
| Product Appearance | 70mm Visible Frame Width | The window has a 70mm visible frame width, with a modern and minimalistic appearance. |
| English Name | Specification / Detail |
|---|---|
| Profile Thickness | 6060-T5 Virgin Aluminium, Main Profile Thickness 1.4mm / Sash Profile Thickness 1.4mm |
| Box Width | 77mm / 118mm |
| Opening Fan Width | 600mm – 1100mm |
| Opening Fan Height | 600mm – 2200mm |
| Glass Configuration | 5mm + 12A + 5mm |
350pa
Water Tightness performance
4.8 m³/(h·㎡)
AirTightness performance
35dB
Sound Insulation performance
2.5 W/(m²·K)
Termal Insulating Porperty
4.3k pa
Wind Pressure Resistance performance
More in Catalog, Download 👉
FAQ About Sliding Window
What are the benefits of aluminium sliding windows?
Aluminium sliding windows are durable, low maintenance, and energy-efficient. They offer smooth, space-saving operation and provide unobstructed views. The aluminium frame ensures resistance to the elements, reducing the risk of rust or decay, making them a long-lasting solution for both residential and commercial properties.
Can aluminium sliding windows be used for large openings?
Yes, aluminium sliding windows are ideal for larger openings, as they can be made with wide spans and offer unobstructed views. The smooth sliding mechanism allows for large window panels without compromising on ease of use or space efficiency.
Are aluminium sliding windows secure?
While aluminium sliding windows provide a good level of security, it is essential to choose models with secure locking mechanisms. Many modern designs come with multi-point locking systems to enhance safety and prevent unauthorized access, making them a reliable choice for both homes and businesses.
What are the drawbacks of aluminium sliding windows?
One of the main drawbacks of aluminium sliding windows is their potential for less airtightness compared to other window types, such as casement windows. This can sometimes lead to reduced thermal performance, especially in extreme weather. However, advanced weather seals can help mitigate this issue.
